Product Description The Siemens 6ED1052-2FB00-0BA6 is a compact LOGO! 8 logic module combining a 12/24 V AC/DC power supply, integrated display and basic I/O in one unit. It offers six universal digital inputs and four relay outputs for straightforward automation tasks. With 400 function blocks of program memory and a microSD-card slot for program backup and cloning, the 12/24RC module is ideal for small machines, building automation and OEM solutions where space is limited and simplicity is paramount.
Key Features Power Supply: 12 … 24 V AC/DC for module and I/O operation
Digital Inputs: 6 universal inputs (12/24 V, DI/AI configurable)
Digital Outputs: 4 relay outputs (250 V AC/30 V DC, 6 A each)
Program Memory: 400 function blocks for custom logic
Display: 4-line LCD for status, parameterization and diagnostics
microSD Slot: Standard microSD card slot for program storage and cloning
Expansion: Supports up to 8 additional I/O expansion modules
Commissioning: Simple on-board navigation with display; no Ethernet or web server
Technical Specifications Parameter Value Supply Voltage 12 … 24 V AC/DC (±10 %) Digital Inputs 6 universal inputs (24 V DC max) Digital Outputs 4 relay outputs, 6 A each Program Memory 400 function blocks Communication Interface None (base unit only) Display 4-line backlit LCD microSD Card Slot for standard microSD (max. 32 GB) Dimensions (W × H × D) 72 mm × 90 mm (4 modules wide) Mounting 35 mm DIN rail Operating Temperature –20 °C … +55 °C Protection Class IP20 Weight ≈ 0.15 kg
Applications Small-scale machine control (pumps, fans, conveyors)
Building automation (lighting, blinds, HVAC startup)
OEM control panels requiring basic logic and display
Compact installations where minimal I/O and no network interface are needed
Advantages All-in-One Design: Combines power supply, display and I/O in one slim module
Easy Programming: 400 function blocks and on-board display simplify configuration
Space-Saving: 72 mm width keeps cabinet footprint small
Program Cloning: microSD slot for fast backup and duplication of logic
Modular Expandability: Additional I/O modules can be added as requirements grow
