Micro850| Allen-Bradley | 2080-LC50-48QWB Micro850 48 I/O EtherNet/IP Controller IN BOX

Product Description: Allen-Bradley 2080-LC50-48QWB

The Allen-Bradley 2080-LC50-48QWB is a high-capacity Micro850 programmable logic controller designed for mid-sized automation applications. With 48 onboard I/O points, built-in Ethernet, embedded analog inputs, and relay outputs, this PLC offers a flexible, compact solution for controlling various discrete and analog processes. It supports plug-in modules and expansion I/O for further system scalability.

Key Features

• 28 digital inputs (24V DC sink/source)
• 20 relay outputs (mechanical contacts, 2 A max per point)
• 4 analog inputs (0–10V DC)
• Embedded 24V DC power supply
• Built-in Ethernet port for programming and communications
• Integrated USB and serial RS-232/RS-485 ports
• Supports up to 4 plug-in modules and expansion I/O
• Real-time clock built-in
• Compatible with Connected Components Workbench (CCW) software

Technical Specifications

• Total I/O: 48 (28 inputs, 20 outputs)
• Input Type: Digital, 24V DC sink/source
• Output Type: Relay
• Analog Inputs: 4 channels, voltage 0–10V DC
• Power Supply: 24V DC
• Communication Ports:
• 1 x Ethernet (10/100 Mbps)
• 1 x USB (programming)
• 1 x Serial (RS-232/RS-485 combo)
• Memory: 512 KB user memory
• Expansion: Supports up to 4 plug-in modules + expansion I/O
• Operating Temperature: 0°C to +55°C
• Mounting: DIN rail
• Enclosure: Open type (IP20)
• Certifications: UL, CE, cULus, KC, RoHS

Application Areas

• Industrial machine control
• Building automation
• Process monitoring and control
• OEM equipment
• Water/wastewater, HVAC, and utility systems

Advantages

• High I/O count supports more complex applications
• Integrated analog inputs for direct process signal monitoring
• Flexible communications with Ethernet and serial ports
• Expandable and modular for future needs
• Cost-effective solution with reliable performance
