Modicon TM3 | Schneider | TM3DQ16R PLC Module Brand New In Box Fast Shipping TM3DQ16R

Product Description: Schneider Electric TM3DQ16R

The Schneider Electric TM3DQ16R is a discrete output expansion module in the Modicon TM3 I/O family. It features 16 relay output channels suitable for switching both AC and DC loads. This module is designed for use with Modicon M221, M241, and M251 logic controllers, providing flexibility for a wide variety of industrial automation and control applications.

Key Features

• 16 relay output channels
• Output voltage: 24 VDC to 250 VAC
• Output current: 2 A max. per channel
• Total current per module: 8 A max.
• 2 groups of 8 outputs (with independent commons)
• Relay type: Form C (SPDT) contacts
• LED indicators for each output channel
• Removable terminal blocks for simplified wiring
• DIN rail mountable

Technical Specifications

• Minimum switching voltage: 5 V
• Minimum switching current: 10 mA
• Maximum resistive load: 2 A per channel
• Isolation: 500 V between relay contacts and logic
• Operating temperature: 0°C to +55°C
• Storage temperature: -40°C to +70°C
• Relative humidity: 5% to 95%, non-condensing
• Protection rating: IP20
• Dimensions (W x H x D): Approx. 90 mm x 90 mm x 70 mm
• Weight: Approx. 0.3 kg

Application Areas

• General- purpose industrial control
• Machine automation and control panels
• Material handling and packaging systems
• HVAC and building automation
• OEM equipment requiring mixed load switching

Advantages

• Supports both AC and DC loads with relay outputs
• Electrically isolated outputs improve safety and system reliability
• Compact and modular design for easy panel integration
• LED indicators simplify troubleshooting and maintenance
• Seamless integration with Modicon logic controllers
