Product Description: Schneider Electric ATV630U22N4

The Schneider Electric ATV630U22N4 is a variable speed drive from the Altivar Process ATV630 series, designed for controlling three- phase asynchronous and synchronous motors in industrial process applications. With a power rating of 2.2 kW (3 HP), the drive operates on a 3-phase 380–480 V AC supply and is tailored for energy efficiency, ease of integration, and superior motor performance in applications such as pumps, fans, and compressors.

Key Features

• Motor power rating: 2.2 kW (3 HP)
• Input voltage: 380–480 V AC, 3-phase
• Output voltage: 0–480 V AC
• Output frequency: 0.1 to 500 Hz
• Control modes: V/F, sensorless flux vector control (SVC), and field-oriented control (FOC) for synchronous motors
• Integrated display with navigation dial and status LEDs
• Built-in Modbus TCP and Ethernet IP communication
• Integrated EMC filter (Category C3)
• Safe Torque Off (STO) as standard
• Conformal coating for harsh industrial environments

Technical Specifications

• Rated output current: 5.4 A
• Line current: 5.6 A
• Overload capacity: 110% for 60 seconds
• Efficiency: ≥ 95%
• Cooling method: Fan-cooled
• Operating temperature: -15°C to +50°C (without derating)
• Storage temperature: -40°C to +70°C
• Relative humidity: 5% to 95%, non- condensing
• Protection rating: IP21 (with top cover), IP20 (standard)
• Mounting: Wall or panel
• Dimensions (W x H x D): 142 mm x 310 mm x 232 mm
• Weight: Approx. 5.2 kg

Application Areas

• Water and wastewater treatment
• HVAC systems
• Pumps and compressors
• Fans and blowers
• General industrial process control

Advantages

• Energy-efficient operation optimized for variable torque loads
• Robust and flexible control of motor performance
• Built-in communication protocols reduce integration costs
• Modular design simplifies maintenance and upgrades
• Real-time diagnostics and energy monitoring
