TeSys F | Schneider | LC1F185 Brand New Schneider Electric 5 Contactor 3P LC1 F18

Product Description: Schneider Electric LC1F185

The Schneider Electric LC1F185 is a heavy-duty 3-pole AC contactor from the TeSys F series, designed for the control of motors up to 90 kW (at 400 V) or for switching resistive loads up to 185 A in AC-3 utilization category. It features a 230 V AC control coil and is built for robust industrial applications requiring reliable switching performance and long service life.

Key Features

• Number of poles: 3P
• Rated current (AC-3): 185 A
• Motor power rating:
  • 90 kW at 400 V AC (AC-3)
• Control voltage: 230 V AC (50/60 Hz)
• Built-in auxiliary contacts: 1 N/O + 1 N/C
• DIN rail or panel mounting
• Screw clamp terminals
• High electrical and mechanical endurance

Technical Specifications

• Rated insulation voltage (Ui): 1000 V
• Rated impulse withstand voltage (Uimp): 8 kV
• Operational frequency: 25–400 Hz
• Mechanical durability: 10 million operations
• Electrical durability: 1 million operations (AC-3)
• Coil consumption:
  • Inrush: ~220 VA
• Operating temperature: -5°C to +60°C
• Storage temperature: -60°C to +80°C
• Protection rating: IP20 (with terminal cover)
• Dimensions (W x H x D): Approx. 155 mm x 194 mm x 174 mm
• Weight: Approx. 5.3 kg

Application Areas

• Motor starters in heavy machinery
• HVAC systems
• Pumps, compressors, and conveyors
• Industrial switching for high-current circuits
• Energy and utility sectors

Advantages

• High switching capacity for large motors and loads
• Reliable performance in demanding industrial conditions
• Compact design for high power density
• Long mechanical and electrical life
• Built-in auxiliary contacts for control circuit flexibility
