Product Description: Schneider Electric TSXDSY16R5

The Schneider Electric TSXDSY16R5 is a digital output module designed for use with the Modicon Premium PLC platform. It provides 16 relay output channels capable of switching both AC and DC voltages, making it highly versatile for controlling various types of loads such as solenoids, contactors, lamps, and small motors.

Key Features

• 16 relay output channels
• Switching voltage: 24 to 240 V AC or DC
• Output type: Relay (mechanical contact)
• Current per output: Up to 2 A
• Output response time: ≤ 10 ms (ON and OFF)
• Grouped in 2 blocks of 8 outputs each
• Common point for each group of 8 outputs
• LED indicators for channel status
• HE10-type connector for field wiring
• Designed for DIN rail mounting

Technical Specifications

• Isolation: 1500 V between output channels and PLC internal circuits
• Minimum switching voltage: 5 V
• Minimum switching current: 10 mA
• Maximum breaking capacity: 250 V AC / 30 V DC
• Maximum output current per module: 8 A
• Contact lifetime: 100,000 operations at full load
• Power consumption: Approx. 110 mA at 5 V DC (from backplane)
• Operating temperature: 0°C to +60°C
• Storage temperature: -25°C to +70°C
• Protection rating: IP20
• Dimensions (W x H x D): Approx. 40 mm x 120 mm x 80 mm
• Weight: Approx. 0.25 kg

Application Areas

• Industrial machinery control
• Lighting control systems
• Building automation
• Material handling and conveyor systems
• Batch processing and control panels

Advantages

• Supports both AC and DC loads for flexible applications
• Relay isolation ensures protection from voltage spikes
• Compact size for high-density installations
• LED status indicators simplify diagnostics
• Reliable switching performance with long contact life
