SINAMICS G120 | Siemens | 6SL3201-0BE14-3AA0 6SL3 201-0BE14-3AA0 SINAMICS BRAKING RESISTOR

Product Description: Siemens 6SL3201-0BE14-3AA0

The Siemens 6SL3201-0BE14-3AA0 is a power module from the SINAMICS G120 modular drive system, specifically the PM240-2 type with frame size FSA. This power module is designed for motor control in general-purpose drive applications and operates on a 3-phase input voltage of 380–480 V AC. It delivers a rated motor output of 4.0 kW and includes an integrated Class A line filter for improved electromagnetic compatibility (EMC). The PM240-2 module is known for its robust performance, compact size, and wide application range. It is designed to work in combination with SINAMICS G120 Control Units (CU230, CU240, CU250 series) and supports vector control, V/f control, and energy-efficient motor operation.

Key Features

• Modular Design: Designed to be paired with G120 Control Units for scalable solutions.
• Integrated EMC Filter: Class A filter ensures EMC compliance without external components.
• Energy- Efficient Operation: Optimized for reduced energy consumption and heat loss.
• Robust Protection: Features overload, short-circuit, and ground fault protection.
• Wide Voltage Range: Accepts 3AC 380–480 V ±10% at 47–63 Hz input frequency.
• Compact Frame Size (FSA): Ideal for panel integration in space- constrained environments.

Technical Specifications

• Product Type: Power Module (PM)
• Part Number: 6SL3201-0BE14-3AA0
• Series: SINAMICS G120
• Power Rating: 4.0 kW (approx. 5.4 HP)
• Input Voltage: 3AC 380–480 V ±10%, 47–63 Hz
• Output Current: Approx. 10 A
• EMC Filter: Integrated, Category C1/Class A
• Cooling: Internal fan cooling
• Frame Size: FSA
• Control Modes Supported: V/f, V/f ECO, Vector Control
• Braking: Integrated braking chopper
• Mounting: Panel-mounted, vertical installation
• Operating Temperature: -10°C to +50°C (derating up to +60°C)
• Protection Class: IP20 (control cabinet installation)
• Weight: Approx. 2.0 kg
• Dimensions (W x H x D): Approx. 73 × 223 × 172 mm

Application Areas

• Pumps and Fans: Variable speed control for HVAC and water systems.
• Conveyors and Mixers: Smooth acceleration/deceleration and torque control.
• General Machinery: Used in automated systems, compressors, packaging, and textile machines.
• Energy- Sensitive Installations: Suitable for systems requiring regenerative or efficient motor operation.

Advantages

• Flexible System Integration: Works with a variety of SINAMICS G120 control units.
• Compact and Modular: Saves panel space and simplifies maintenance.
• Pre-Integrated EMC Compliance: Reduces the need for external filtering hardware.
• Reliable Performance: Industrial-grade design ensures high uptime and operational safety.
• Optimized for Efficiency: Supports energy-saving applications with reduced harmonic distortion.
