SINAMICS G120 | Siemens | 6SL3 244-0BB12-1BA1 6SL3244-0BB12-1BA1 SINAMICS G120 CONTROL UNIT

Product Description: 6SL3244-0BB12-1BA1

The 6SL3244-0BB12-1BA1 is a PM240-2 power module from the SINAMICS G120 family, rated at 55 kW motor output. It converts three-phase 380–480 V AC into a regulated DC link and drives the motor stage in modular G120 systems. This variant includes an integrated C1-class EMC filter, ensuring compliance with electromagnetic-compatibility standards without external components. Housed in a compact Frame Size F enclosure with internal fan cooling, it pairs with G120 control units (CU) to deliver high-performance drive solutions.

Key Features

• 55 kW Continuous Power in a single PM module
• Integrated C1 EMC Filter for reduced RFI/EMI
• Braking Chopper Built-In to handle regenerative energy (external resistor required)
• Modular Design works with CU230/CU240/CU250 control units
• Internal Fan Cooling for reliable temperature management
• Integrated Protection: Overvoltage, overcurrent, short- circuit, and overtemperature

Technical Specifications

• Rated Motor Power: 55 kW (75 HP)
• Input Voltage: 3AC 380 – 480 V ±10 %, 47–63 Hz
• Output Current: ≈ 98 A continuous
• DC Link Voltage: ≈ 600 V DC
• EMC Filter: Integrated C1 (EN 61800-3 Category C1)
• Braking Chopper: Integrated (external braking resistor required)
• Cooling Method: Internal fan
• Frame Size: F
• Protection Class: IP20 (cabinet-mounted)
• Communication Interface: DRIVE-CLiQ to CU
• Dimensions (W×H×D): ≈ 275 × 700 × 320 mm
• Weight: ≈ 38 kg

Application Areas

• High-power conveyor systems and material handling
• Large pump, fan, and compressor drives
• Plastic extrusion, cooling towers, and industrial HVAC
• Machine tools requiring regenerative braking

Advantages

• Pre-Integrated EMC Compliance: C1 filter saves panel space and wiring
• Energy Recovery Ready: Built-in chopper enables dynamic braking
• Scalable Modular System: Combine with various CUs for tailored solutions
• Robust Industrial Design: Proven reliability under harsh conditions
• Simplified Engineering: Full configuration support in Siemens STARTER or TIA Portal
