Product Description: Schneider Electric TM221CE40R

The Schneider Electric TM221CE40R is a compact and powerful logic controller from the Modicon M221 series, designed for high- speed control of small to medium-sized machines. It features 40 integrated I/O points and includes Ethernet and serial communication ports for easy integration. With relay outputs and a 24 V DC power supply, it supports flexible machine control in a wide range of industrial applications.

Key Features

• 40 integrated I/O:
• 24 digital inputs (24 V DC)
• 16 relay outputs (2 A max. per channel)
• Power supply: 24 V DC
• Communication ports:
• 1 x Ethernet port (10/100 Mbps)
• 1 x USB mini-B programming port
• 1 x serial port (RS232/RS485, Modbus Master/Slave)
• SD card slot for program backup and data logging
• Integrated real-time clock
• Expandable with Modicon TM3 I/O modules
• Programming via EcoStruxure Machine Expert - Basic

Technical Specifications

• Input voltage range: 20.4–28.8 V DC
• Relay output rating: 2 A at 250 V AC or 30 V DC
• Maximum total output current: 8 A
• Program memory: 256 kB
• Data memory: 64 kB
• Processing speed: 1 µs per instruction
• Operating temperature: 0°C to +55°C
• Storage temperature: -40°C to +70°C
• Relative humidity: 5% to 95%, non-condensing
• Protection rating: IP20
• Mounting: DIN rail
• Dimensions (W x H x D): Approx. 142.5 mm x 90 mm x 71.5 mm
• Weight: Approx. 0.7 kg

Application Areas

• Compact machine control
• Packaging, bottling, and labeling machines
• HVAC and pump systems
• Conveyors and material handling
• Building automation and process control

Advantages

• Built-in Ethernet for seamless integration
• High-speed processing for fast machine cycles
• Expandable and flexible architecture
• Easy configuration and programming
• Reliable and compact solution for OEMs and panel builders
