Drive | Siemens | 6SE6400-4BD16-5CA0 6SE6 400-4BD16-5CA0 MICROMASTER Braking resistor

Product Description: Siemens 6SE6400-4BD16-5CA0

The Siemens 6SE6400-4BD16-5CA0 is a Basic Operator Panel (BOP) designed for use with the MICROMASTER 4 series frequency inverters. It provides a user- friendly interface for commissioning, monitoring, and local control of drive parameters. Featuring a 5-digit display and keypad with navigation buttons, the BOP allows easy access to status data and parameter settings, making it ideal for field-level configuration and diagnostics of MICROMASTER drives.

Key Features

• Display: 5-digit LED display for real-time values and parameters
• Operation: Navigation keys for parameter selection and modification
• Mounting: Pluggable directly onto MICROMASTER 4 drives or remote mounting via cable
• Functionality: Start/stop control, parameter read/write, fault display
• Language Support: Multilingual interface with parameter codes
• Compatibility: All MICROMASTER 420/430/440 frequency inverters

Technical Specifications

• Product Type: Basic Operator Panel (BOP)
• Display Type: 5-digit LED
• Interface: RS485 (internal communication with drive)
• Control Functions: Start, stop, setpoint entry, diagnostics
• Mounting Type: Plug- in or panel mount (with accessories)
• Operating Temperature Range: 0 °C to +50 °C
• Dimensions (W × H × D): Approx. 70 mm × 30 mm × 30 mm
• Power Supply: Powered by the drive
• Certifications: CE, cULus

Application Areas

• Local commissioning of MICROMASTER drives
• On-site parameter monitoring and adjustment
• Diagnostics and fault management in industrial environments
• Operator interface for basic drive control

Advantages

• Simple, cost-effective commissioning tool
• Improves usability of MICROMASTER drives without external tools
• Quick access to parameter settings and operational feedback
• Compatible with the full MICROMASTER 4 drive range
